Fiberon™ PA612-CF15 is a carbon fiber reinforced long chain copolyimide filament. Thanks to its chemical structure, this product has lower moisture sensitivity compared to PA6/66 and PA6-based materials, and better mechanical properties than PA12-based materials. In addition, the carbon fiber reinforcement and Warpfree™ technology enhance the size stability of the prints produced with this material.
Fiberon™ PA612-CF15 is the same great formula as PolyMide PA612-CF, although Fiberon™ PA612-CF15 may print in a slightly darker black shade color than its predecessor.
Printing Temperature:
250˚C - 300˚C
Bed Temperature:
25˚C - 50˚C
Printing Speed:
30mm/s -60mm/s
Fan:
OFF
Direct Drive Retraction Distance:
3mm
Direct Drive Retraction Speed:
40mm/s
Indirect Drive Retraction Distance:
6mm
Indirect Drive Retraction Speed:
60mm/s
Drying Settings:
100˚C for 8h
Dry Settings Notes:
(Only if the material has absorbed moisture)
Annealing:
80˚C for 6h
DISCLAIMER:
The created printing profiles are intended for reference only. They should not be used for design specifications or quality control purposes.
End-use performance of printed parts depends not only on materials and printing conditions but also on part design, environmental conditions, etc. Printing profiles are subject to change without notice. Each user is responsible for determining the safety, lawfulness, and technical suitability of recommended printing profiles for the intended application. Polymaker makes no warranty of any kind unless announced separately, to the fitness for any use or application. Polymaker shall not be made liable for any damage, injury or loss induced by the use of recommended printing profiles in any application.
