PolyMide™ CoPA is a copolymer of Nylon 6 and Nylon 6.6 combining high tensile strength properties from Nylon 6 with heat resistance properties from Nylon 6.6. Warp- Free™ technology provides ease of printing by slowing down the crystallization allowing CoPA to be easily printed on open bed printers. Displaying outstanding mechanical and thermal properties, CoPA is suited for parts in demanding environments.
Printing Temperature:
250˚C - 270˚C
Bed Temperature:
25˚C - 50˚C
Printing Speed:
30mm/s -50mm/s
Fan:
OFF
Direct Drive Retraction Distance:
3mm
Direct Drive Retraction Speed:
50mm/s
Indirect Drive Retraction Distance:
6mm
Indirect Drive Retraction Speed:
60mm
Drying Settings:
80˚C for 6h
Dry Settings Notes:
(Only if the material has absorbed moisture)
Annealing:
80˚C for 6h
DISCLAIMER:
The created printing profiles are intended for reference only. They should not be used for design specifications or quality control purposes.
End-use performance of printed parts depends not only on materials and printing conditions but also on part design, environmental conditions, etc. Printing profiles are subject to change without notice. Each user is responsible for determining the safety, lawfulness, and technical suitability of recommended printing profiles for the intended application. Polymaker makes no warranty of any kind unless announced separately, to the fitness for any use or application. Polymaker shall not be made liable for any damage, injury or loss induced by the use of recommended printing profiles in any application.
